Captrate® Solo Filter The CaptiveAire Captrate® Solo filter is a single-stage filter which features a unique S-baffle design in conjunction with a slotted rear baffle design.    Standard Features and Benefits     Construction: Filter is constructed of 430 stainless steel and sized to fit into standard two inch deep hood channels. Cleaning: Single unit assembly design does not require any components to be separated for cleaning and maintenance. Grease Extraction: Grease extraction performance shall remove 90% of grease particles seven microns in size and larger and at least 75% of grease particles 5 microns in size and as measured by ASTM F2519-05 Standard Test Method for Grease Particle Capture Efficiency of Commercial Kitchen Filters and Extractors. ETL Listed: ETL Listed and meets UL Standard 1046.    Additional Information     Brochure for Captrate® Captrate® Frequently Asked Questions Captrate® User Manual Captrate® Combo Filter The CaptiveAire Captrate® Combo filter uses multi-stage grease filtration, delivering unparalleled efficiency for restaurant hood systems. The first stage consists of a unique S-Baffle to remove and drain the larger grease particles. The second stage features a packed bed of porous ceramic media, designed to capture the fine grease aerosol particles associated with commercial cooking.    Standard Features and Benefits     Construction: Metallic components constructed of 430 stainless steel and durable micro-porous ceramic media capable of absorbing smaller grease particles by means of capillary action. Construction: Sized to fit into standard two inch deep hood channels. Grease Extraction: Grease extraction performance shall remove at least 98% of grease particles four microns in size and at least 85% of grease particles two microns in size and larger as measured by ASTM F2519-05 Standard Test Method for Grease Particle Capture Efficiency of Commercial Kitchen Filters and Extractors. ETL Listed: ETL Listed and meets UL Standard 1046.    Additional Information     Brochure for Captrate® Captrate® Frequently Asked Questions Captrate® User Manual CaptiveAire Filter Collection Efficiency Comparison The filters were tested to ASTM Standard F2519-05 by an independent third party. The purpose of the ASTM standard is to determine the grease particle collection efficiency of filters used in commercial kitchens to capture grease effluent prior to entering the grease duct.
